Large Burner: 11 3/4″ | 3,000 Watts
Medium Burner: 10 5/8″ | 1,700 Watts
Control Panel: Measures 8 3/4″ x 5 1/2″
Electrical Requirements: 220 Volts, 1P + N with 40 amps. PLEASE BE SURE NO NEUTRAL/WHITE WIRE IS CONNECTED.
Minimum Countertop thickness: 1 inch
*Underneath your induction glass, there is a generator, that is about 3 to 4 inches.
Minimum distance between burners: 3″
Large Burner Template
Medium Burner Template
*Please note: If you need a DXF file please email [email protected]*
**To ensure maximum inductive efficiency, please make sure that your cookware never exceeds the diameter of the coil.**
